The ESPS and ESTS series are engine-mounted oil pressure and coolant temperature measurement sensors with both resistive sender and fault limit switch outputs.
The resistive sender outputs have the same pressure/temperature versus resistance characteristics as the Murphy ES series senders, allowing use with EG(S)21 series gauges or Swichgages, engine/genset controllers or input/output modules (e.g. the Murphy MeCAN™ interface).
Switch output contacts are normally open (at normal running pressures and temperatures), with the contacts closing to sensor body/case ground when pressure falls below, or temperature rises above, the factory set limits. The switch outputs can be used with external control devices to signal fault conditions, and trigger operator warning and/or engine shutdown protection. For example, the contacts can be used in place of, or in addition to, EG(S)21 Swichgage outputs, to provide two-staged limits for warning and shutdown.
EMEA Region Only
ESPS pressure models
ESTS temperature models
WARNING: This product may expose you to chemicals which are known to the State of California to cause cancer, birth defects or other reproductive harm. For more information about California Propsition 65, go to www.P65Warnings.ca.gov or visit our California Proposition 65 page.Additional product documentation can be found on our product support website or by clicking the Help Center button above.
| Part Number | Model | Description |
|---|---|---|
| 05707753 | ESPS-100 | ESPS-100 pressure sender/switch, 1/8” NPT thread, sender range 0-100 PSI, switch set at 15 PSI |
| 10703807 | ESTS-250 | ESTS-250 temperature sender/switch, 5/8” -18 UNF thread, sender range 38 – 121°C / 100 – 250°F, switch set at 105°C / 221°F |
| 10703808 | ESTS-300 | ESTS-300 temperature sender/switch, 5/8” -18 UNF thread, sender range 38 – 148°C / 100 – 300°F, switch set at 130°C / 266°F |
| Note: ESPS and ESTS orders are subject to a minimum order quantity of 100 units. |
